SANT Bronze Globe Steam Stop Valve IBR 1A (Screwed)

SANT IBR 1A

SANT Bronze Globe Steam Stop Valve IBR 1A (Screwed)

Visit the SANT Store

SKU : SANT-IBR1A8

HSN Code : 8481

Categories : Globe Valve

Download Price List

SANT

Size (Inch/ MM) : 1/4 Inch - 8 MM

1/4 Inch - 8 MM 3/8 Inch - 10 MM 1/2 Inch - 15 MM 3/4 Inch - 20 MM 1 Inch - 25 MM 1-1/4 Inch - 32 MM 1-1/2 Inch - 40 MM 2 Inch - 50 MM

Body
Bronze
Pressure Rating (PN)
250 psig (17.58 kg/cm²)
Seat/Stem
Renewable seat
Test Pressure
500 psig (35.15 kg/cm²)
Body tested pressure
Renewable disc
Temperature Rating
435°F (225°C)
Trim
SS AISI410
Gland Packing
Graphited Asbestos
Pressure Rating (PN)
250 psig (17.58 kg/cm²)
Description
Yoke Type Rising Stem
End Connections
Screwed female BSP Taper threads to BS 21
